Getting Started
Activate your new device before use. Download DJI Assistant 2 (Consumer Drone Series), connect your device to a computer, and activate it following the prompts.
Activation step-by-step guide
1. Visit DJI's official website download page.
2. Download DJI Assistant 2 (Consumer Drones Series) to your computer.
3. Connect DJI O3 Air Unit to your computer using a USB-C cable.
4. Launch DJI Assistant 2, and enter your DJI account and password to log in.
5. After the device is connected to the computer successfully, click the DJI O3 Air Unit icon, and it will prompt you to activate the device. Click "Start Activation".
6. Click "Next" to complete the activation process.
Watch the video to activate your device:
https://www.dji.com/o3-air-unit/video
Firmware Update
Ensure both devices are updated to the latest firmware.
1. Connect the air unit to the computer using a USB-C cable.
2. Launch DJI Assistant 2(Consumer Drone Series).
3. Click "Firmware Update", select the latest firmware version, click "Update", and wait until the update is complete.
4. Restart the device upon completion of the update.
Note: DJI O3 Air Unit and DJI Goggles 3 and DJI Goggles 3 need to be updated to the latest version to be compatible.
Linking/Binding the air unit to the goggles
1. Power on the goggles and air unit, and press the link button on the goggles. The goggles start to beep continually, indicating that they have entered the linking state.
2. Press the link button of the air unit, and the live view will appear on the googles once the linking is successful.
* When the linking status indicator of the air unit changes from green to red, it indicates that it has been linked. The status indicator will become solid green once the linking is successful.
For more instructions, refer to DJI's guide here: https://www.dji.com/au/o3-air-unit/video
